| General information |
|---|
| Model: | Kawasaki Ninja ZX-10R |
| Year: | 2009 |
| Category: | Sport |
| Rating: | 70.8 out of 100. Show full rating and compare with other bikes |
| Safety: | See our safety campaign with the high safety rated bikes in this category. |
| Engine and transmission |
|---|
| Displacement: | 998.00 ccm (60.90 cubic inches) |
| Engine type: | In-line four |
| Stroke: | 4 |
| Torque: | 112.81 Nm (11.5 kgf-m or 83.2 ft.lbs) @ 8700 RPM |
| Compression: | 12.9:1 |
| Bore x stroke: | 76.0 x 55.0 mm (3.0 x 2.2 inches) |
| Fuel system: | Injection. DFI with 43mm Keihin throttle bodies with oval sub-throttles, two injectors per cylinder |
| Valves per cylinder: | 4 |
| Fuel control: | DOHC |
| Ignition: | TCBI with digital advance and Kawasaki Ignition Management System (KIMS) |
| Starter: | Electric |
| Cooling system: | Liquid |
| Gearbox: | 6-speed |
Transmission type
final drive: | Chain |
| Physical measures |
|---|
| Dry weight: | 208.0 kg (458.6 pounds) |
| Seat height: | 831 mm (32.7 inches) If adjustable, lowest setting. |
| Overall height: | 1,135 mm (44.7 inches) |
| Overall length: | 2,111 mm (83.1 inches) |
| Overall width: | 711 mm (28.0 inches) |
| Wheelbase: | 1,415 mm (55.7 inches) |
| Chassis and dimensions |
|---|
| Rake (fork angle): | 25.5° |
| Trail: | 109 mm (4.3 inches) |
| Front suspension: | 43mm inverted fork with DLC coating, adjustable rebound and compression damping, spring preload adjustability and top-out springs / 4.7 in. |
| Rear suspension: | Uni-Trak® with top-out spring, stepless, dual-range (high/low-speed) compression damping, stepless rebound damping, fully adjustable spring preload / 4.9 in. |
| Front tyre dimensions: | 120/70-ZR17 |
| Rear tyre dimensions: | 190/55-ZR17 |
| Front brakes: | Double disc |
| Front brakes diameter: | 310 mm (12.2 inches) |
| Rear brakes: | Single disc |
| Rear brakes diameter: | 220 mm (8.7 inches) |
| Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 17.03 litres (4.50 gallons) |
| Color options: | Ebony, Candy Burnt Orange/Flat Super Black, Special Edition Lime Green/Metallic Diablo Black |
